Maniglia diffondi aromi

in preziosa ceramica

Poignée diffuseur en

c

éramique précieuse

Precious ceramic handle

with aroma diffusor

Piano igienico,

in cristallo

Plateau hygi

énique

en cristal

Hygienic glass top

Schermo comandi programmabile

Panneau des commandes

programmable

Programmable control

screen, with remote control

Maniglia removibile.

Essenzialità nel design

e maggior sicurezza

Poignée amovible.

Design essentiel

et sécurité accrue

Removable handle.

Essentiality in design

and greater safety.

Simplified cleaning system

• iCONTROL (optional)

Sistema wi-fi iControl con web-App

Système wi-fi iControl avec web-App

Wi-fi system iControl with web-App

Wi-Fi System iControl mit web-App

Sistema wi-fi iControl con web-App

• ROOM CONTROL (optional)

Termostato ambiente wireless con supporto a muro.

Thermostat d'ambiance wireless avec support mural.

Room wireless Thermostat with its wall support.

Kabelloser Raumthermostat mit Wandhalterung.

Termostato de habitaci

ón wireless con su soporte de pared.

Bianco

Grigio

Bordeaux

Stone

• Dinner (optional) (a)

Coperchio scalda vivande in cristallo;

Warmhalteplatte aus Kristallglas;

Couvercle chauffe-plat en crystal;

Glass food-warming cover;

Chapa para calentar comidas;

Porta focolare in vetro

ceramico serigrafato e ghisa

Porte de foyer en fonte et

cristal imprim

é en sérigraphie

Screen-printed ceramic glass

and cast iron firebox door

(b)

(a) Solo per versione “Air - Plus”

(b)

(a) Uniquement version “Air - Plus”

(b)

(a) Only on “Air - Plus” version

(b)

(b)

Piano salva cenere

Base ramasse-cendre

Protective ash pan

*

Air/Plus ............................... 107

N.Air/N.Plus 12 ....................103

Air......................1127x518x596

mm

Plus .................. 1127x518x596

N.Air .................1132x518x593

N.Plus ...............1132x518x593

Air/Plus ......................3,8 - 12,9

kW

N.Air/N.Plus 12 .......... 3,2 - 12,3

Air/Plus ......................3,5 - 12,1

kW

N.Air/N.Plus 12 ..........3,1 - 11,4

NOM.

Air/Plus ........................0,8 - 2,7

N.Air/N.Plus 12 ............ 0,7 - 2,6

Air...........................................19

Plus ........................................15

N.Air ...................................20,7

N.Plus .................................17,2

MAX

MIN

Solo per versione “Natural Air - Natural Plus”

Uniquement version “Natural Air - Natural Plus”

Only on “Natural Air - Natural Plus” version

MAX

MIN

BlmSchV II

mechanical

safety devices

MULTI

Dress Code

(c) Solo per versione “Plus - Natural Plus”

(c) Uniquement version “Plus - Natural Plus”

(c) Only on “Plus - Natural Plus” version

La tipologia di fiamma ed il focolare possono variare a seconda delle versioni

Le type de flamme et le foyer peuvent varier selon les versions

Flame and the firebox can vary according to different model

16mx1

8mx2

16mx1

8mx2

Air

Natural Air

Plus

Natural Plus

Pellet

Power

ESSENZA

metalcolor
