Vano scaldavivande

con piano igienico in cristallo

Chauffe-plats avec plateau en

verre hygi

énique

Food warming compartment

with Plate in hygienic glass

• iCONTROL (optional)

Sistema wi-fi iControl con web-App

Système wi-fi iControl avec web-App

Wi-fi system iControl with web-App

Wi-Fi System iControl mit web-App

Sistema wi-fi iControl con web-App

• ROOM CONTROL (optional)

Termostato ambiente wireless con supporto a muro.

Thermostat d'ambiance wireless avec support mural.

Room wireless Thermostat with its wall support.

Kabelloser Raumthermostat mit Wandhalterung.

Termostato de habitaci

ón wireless con su soporte de pared.

• INTEGRA TR-PACK (optional)(b)

Thermocell® (250/400/500 lt)

Thermopuffer (400/500/1500 lt)

Thermosole® (2.0)

• Thermofan (optional)(b)

kit di ventilazione termostufa

Raumluftventilator f

ür Pelletsofenwassergeführt

Pellet thermo-stoves air convection kit

Kit de ventilation thermo-po

êle

Pellet thermo-stoves kit de convecci

ón de aire

Bianco

Beige

Tortora

Bordeaux

Bianco

Tortora

Preziosa maiolica artigianale

fatta a mano

Précieuses c

éramiques

artisanales faites à la main

Precious handmade majolica tiles

(b)

Porta focolare in vetro ceramico serigrafato e ghisa

Porte de foyer en fonte et cristal imprimé en s

érigraphie

Screen-printed ceramic glass and cast iron firebox door

• Valvola termostatica a 3 vie

1" FFF 55 OT (optional);

Thermostatic valve 3 ways

1" FFF 55 OT (optional);

Vannethermostatique3voies

1" FFF 55 OT (optional);

• Sonda PT100 (optional-min 2 pz)

per funzione «THERMOCONTROL»;

PT100 sensor (optional-min 2 pc)

for «THERMOCONTROL» function;

SondePT100(optional-min2pces)

pour fonction «THERMOCONTROL»;

(a)

(b)

Air/Plus ...................107

Idra14 ..................... 118

Idra18 ..................... 160

Idra21 ..................... 191

Air/Plus 1323x660x644

mm

Idra14 1323x660x644

Idra18 1323x660x644

Idra21 1323x660x644

Air/Plus .........3,8 - 12,9

Idra14 ........... 5,3 - 13,7

Idra18 ........... 5,4 - 18,9 kW

Idra21 ........... 5,3 - 22,5

Air/Plus .........3,5 - 12,1

kW

Idra14 ........... 5,1 - 13,1

Idra18 ........... 5,3 - 17,8 NOM.

Idra21 ........... 5,1 - 21,2

Idra14 ........... 3,8 - 10,9

Idra18 ........... 3,7 - 15,0

Idra21 ........... 3,8 - 17,9

Air/Plus .......... 0,8 - 2,7

Idra14 ............. 1,1 - 2,8

Idra18 ............. 1,1 - 3,9

Idra21 ............. 1,1 - 4,6

Air.............................. 19

Plus ........................... 15

Idra 14/18/21 ............22

MAX

MAX

*

mechanical

safety devices

BlmSchV II

Air

Plus

Idra 14

Idra 18

Idra 21

MIN

MIN

16mx1

8mx2

Pellet

Power

(a) Solo per versione “Air” e “Plus”

(a) Uniquement version “Air” e “Plus”

(a) Only on “Air” e “Plus” version

(b) Solo per versione “Idra14-18-21”

(b) Uniquement version “Idra14-18-21”

(b) Only on “Idra14-18-21” version

La tipologia di fiamma ed il focolare possono variare a seconda delle versioni

Le type de flamme et le foyer peuvent varier selon les versions

Flame and the firebox can vary according to different model
