Gomito a 90

°

PE100RC - S5 Gas - PN 16 20°

C

P

d

L

PE100 - SDR11 - S

5

ACQUA: PFA (PN)=16 bar 20°C

GAS: MOP=10 bar; In Italia MOP=5 bar (D.M. 24/11/84, D.M. 16/4/2008 e successive modi

fiche

)

Per il tempo di saldatura da utilizzare con tubo SDR26 contattare direttamente Unidelta.

DI

M

dxd [mm]

CODE

LxHxP [mm

]

DIM MAX

L

[mm]

P

[mm] W-SDR

PACK [UMV]

RIF. 10

RIF. 11

RIF. 2

RIF. 5

Sfus

i

20x20

3004021000001

62x62x50

62

50

≤ 11

-

40

-

-

-

25x25

3004026000001

69x69x55

69

55

≤ 11

-

25

-

-

-

32x32

3004033000001

77x77x62

77

62

≤ 11

-

20

-

-

-

40x40

3004041000001

88x88x71

88

71

≤ 17

-

12

-

-

-

50x50

3004051000001

103x103x82

103

82

≤ 17

-

10

-

-

-

63x63

3004064000001

121x121x96

121

96

≤ 17

-

-

10

-

-

75x75

3004076000001

142x142x109

142

109

≤ 17

-

-

8

-

-

90x90

3004091000001

166x166x126

166

126

≤ 17

16

-

-

-

-

110x110

3004111000001

198x198x148

198

148

≤ 17

-

-

-

10

-

125x125

3004125000001

240x240x175

240

175

≤ 17

-

-

-

6

-

*140x140

3004140000001

265x265x185

265

185

≤ 17

-

-

-

-

1

160x160

3004160000001

305x305x220

305

220

≤ 17

-

-

-

2

-

180x180

3004180000001

310x310x240

310

240

≤ 17

-

-

-

2

-

200x200

3004200000001

350x350x260

350

260

≤ 17

-

-

-

2

-

225x225

3004225000001

350x350x260

350

260

≤ 17

-

-

-

-

1

250x250

3004250000001

425x425x325

425

325

≤ 17

-

-

-

-

1

* Disponibile solo a spira scopert

a
