Collegamento tra componenti del sistema a doppio o-ring Euroti

s

Connection between Eurotis double o-ring system components

Collegamenti tra due tubi CSST con lo stesso DN

Mediante raccordo di unione M/M con tenuta su doppio o-ring

.

Connection between PLT-CSST tubes with same DN

Through M/M connection

fitting with tightness on double o-ring.

Collegamento tra componenti del si-

stema a doppio o-ring Eurotis e altr

i

sistemi / materiali

Durante le fasi di installazione, un passaggio fondamentale

è il taglio del tubo. Utilizzando un tagliatubi Eurotis, la lama

va posizionata all’interno delle due corrugazioni e si procede

con il taglio

fino al completo distacco del tubo. È importan-

te evitare di strapparlo, accompagnando invece il taglio i

n

modo graduale e delicato

.

Per collegare un tubo CSST ad altri sistemi o materiali si de

-

vono utilizzare sempre ed unicamente gli appositi raccordi

di unione. Per garantire la tenuta in pressione sulla

filettatur

a

si devono sempre utilizzare, sia per

filettature di tipo paral-

lelo (cilindrico) che conico, prodotti a tenuta conformi all

e

norme della serie EN 751 (ad esempio: sigillanti, canapa,

fi-

bre sintetiche, nastri di te

flon, etc.) accertandosi della loro

compatibilità con il

fluido trasportato.

Connection between Eurotis double

o-ring system components and othe

r

systems / materials

During the installation phases, a fundamental step is cutting

the pipe. Using a Eurotis pipe cutter, the blade should be po-

sitioned between the two corrugations and the cut carried

out until the pipe is completely separated. It is important not

to tear the pipe, but to guide the cut smoothly and gently.

Do not join PLT-CSST tubes to other systems or materials

with direct connection through nuts, reduced nuts, simple

screws or reduced simple screws. To join a PLT-CSST tub

e

to other systems or materials use always and only specif

-

ic connection

fittings. To assure pressure tightness always

use, both for parallel (cylindrical) and for taper threads

,

sealing materials conform to EN 751 standards (for example

:

dopes, hemp, synthetic fibers, teflon tapes, etc.) checkin

g

their compatibility with the supplied

fluid.

Collegamento tra un tubo CSST e un terminale

filettato femmina

Connection between a PLT-CSST tube and a female thread en

d

Mediante raccordo di unione M/M con tenuta su o-ring (lato

tubo CSST) e con l’altra estremità

filettata maschio ISO 228 G

.

Through a M/M connection

fitting with tightness on o-ring

(CSST tube side) and the other end with ISO 228 G male

thread

.

Mediante raccordo di unione ridotto M/M con tenuta su

o-ring (lato tubo CSST) e con l’altra estremità filettata ma-

schio EN 10226 R

.

Through a M/M reduced connection fitting with tightness o

n

o-ring (CSST tube side) and the other end with EN 10226

R

male taper thread.

Sistemi Eurotis / Eurotis systems
