Uscite per canalizzazione disponibili:
due posteriori (c)
Sorties de canalisation disponibles :
2 arri
ères (c)
Available ducting outlets:
two rear (c)
Schermo comandi programmabile
Panneau des commandes
programmable
Programmable control
screen, with remote control
• iCONTROL (optional)
Sistema wi-fi iControl con web-App
Système wi-fi iControl avec web-App
Wi-fi system iControl with web-App
Wi-Fi System iControl mit web-App
Sistema wi-fi iControl con web-App
• ROOM CONTROL (optional)
Termostato ambiente wireless con supporto a muro.
Thermostat d'ambiance wireless avec support mural.
Room wireless Thermostat with its wall support.
Kabelloser Raumthermostat mit Wandhalterung.
Termostato de habitaci
ón wireless con su soporte de pared.
Bianco
Tortora
Bordeaux
Nero
opaco
Top in cristallo con funzione Natural
a qualsiasi potenza
Crystal glass top with Natural function
at any power
Top en cristal avec fonction Natural
à
tous les niveaux de puissance
Preziosa maiolica artigianale
fatta a mano
Pr
écieuses céramiques
artisanales faites
à la main
Precious handmade majolica tiles
Porta focolare in vetro
ceramico serigrafato
e ghisa
Porte de foyer en fonte
et cristal imprim
é en sérigraphie
Screen-printed ceramic
glass and cast iron firebox door
Bruciatore brevettato Pelletpower® (b)
Br
ûleur breveté Pellet Power®
Patented PelletPower® burner (b)
• Dinner (optional) (a)
Coperchio scalda vivande in cristallo;
Warmhalteplatte aus Kristallglas;
Couvercle chauffe-plat en crystal;
Glass food-warming cover;
Chapa para calentar comidas;
Air/Plus ............................... 107
N.Air/N.Plus 12 ....................103
Air..................... 1130x565x648
Plus .................. 1130x565x648
N.Air .................1130x565x644
N.Plus ...............1130x565x644
mm
(b)
Air/Plus ......................3,8 - 12,9
kW
N.Air/N.Plus 12 .......... 3,2 - 12,3
Air/Plus ......................3,5 - 12,1
kW
N.Air/N.Plus 12 ..........3,1 - 11,4
NOM.
Air/Plus ........................0,8 - 2,7
N.Air/N.Plus 12 ............ 0,7 - 2,6
Air...........................................19
Plus ........................................15
N.Air ...................................20,7
N.Plus .................................17,2
*
(b)
(a) Solo per versione “Air - Plus”
(a) Uniquement version “Air - Plus”
(a) Only on “Air - Plus” version
MAX
MIN
MAX
MIN
BlmSchV II
mechanical
safety devices
MULTI
Dress Code
(b) Solo per versione “Natural Air - Natural Plus”
(b) Uniquement version “Natural Air - Natural Plus”
(b) Only on “Natural Air - Natural Plus” version
(c) Solo per versione “Plus - Natural Plus”
(c) Uniquement version “Plus - Natural Plus”
(c) Only on “Plus - Natural Plus” version
La tipologia di fiamma ed il focolare possono variare a seconda delle versioni
Le type de flamme et le foyer peuvent varier selon les versions
Flame and the firebox can vary according to different model
16mx1
8mx2
16mx1
8mx2
Air
Natural Air
Plus
Natural Plus
Pellet
Power
