I diametri delle sezioni delle tubazioni costituenti l’impiant

o

gas devono essere tali da garantire una fornitura di gas suf

fi-

ciente a coprire la richiesta, limitando la perdita di pression

e

(perdita di carico) fra il contatore e qualsiasi apparecchio d

i

utilizzazione a valori non maggiori di 1 mbar per i gas della 2°

famiglia (metano) e 2 mbar per i gas della 3° famiglia (GPL).

For the sizing of the gas plant all the possible municipal, re-

gional or national requirements shall be always respected

.

The tables of the flows of the PLT-CSST tubes and of the

equivalent lengths of the direction changes, fittings and taps

(valves) are available on the technical documentation o

n

www.eurotis.it

.

Staffaggio ed ancoraggio

Clamping and fastening of the tubes

D

N

Dimensione nominale del tubo CSST

Tube nominal dimensio

n

Installazione a vista

At sight installatio

n

Installazione in canaletta o in nicchi

a

Installation in cubbies or loglines

DN 10 - DN 15

DN 20 - DN 32

DN 40 - DN 50

Orizzontal

e

Horizonta

l

1,2 m

1,8 m

1,8 m

Verticale

Vertical

1,2 m

1,8 m

1,8 m

Verticale

Vertical

3 m

3 m

3 m

Attenzione / Attention

Eurotis produce diversi tipi di tubazioni per gas che

hanno caratteristiche ed impieghi differenti

.

Eurotis produces different types of tubes for gas which

have different characteristics and use

s

IMPIANTI GAS DOMESTICI E SIMILARI

EUROGW / EUROGAS: sono tubazioni corrugate formabi-

li (non flessibili) CSST in acciaio inossidabile austenitico AISI

316L con rivestimento protettivo certificate a norma UNI EN

15266 che possono essere utilizzate negli impianti gas dome

-

stici e similari dal contatore del gas fino agli apparecchi di uti-

lizzazione compreso il collegamento diretto ad apparecchi d

i

tipo fisso o ad incasso con l’esclusione quindi del collegament

o

diretto ad apparecchiature mobili come previsto dalla norma d

i

installazione UNI 7129 : 2015. I tubi CSST EUROGW / EURO-

GAS non sono tubi flessibili e quindi non hanno limitazioni nella

loro lunghezza

.

DOMESTIC AND SIMILAR GAS PLANTS

EUROGW / EUROGAS: are PLT-CSST (Corrugated Stein

-

less Steel Tubing) pliable corrugated tubes (not flexible hoses

)

in AISI 316L austenitic stainless steel with external protective

covering certi

fied according to EN 15266 standard which ca

n

be used, as specified in the national rules, in domestic and sim-

ilar gas installations from the gas meter up to the gas appli-

ances including the direct connection to the fixed appliances

thus excluding the direct connection to mobile appliances

.

The PLT-CSST EUROGW / EUROGAS tubes are not flexible

hoses and so there is not a limitation in their length

.

Sistemi Eurotis / Eurotis systems

37
