Dati tecnici e ordinazione

Optyma

TM

Plus New Generation - LBP

Parti di ricambio

Unità

Ricevitore [L]]

Condensatore

ventola [μF]

Motore vemtilatore

[W] (condensatore

non incluso)

Pala ventilatore

[mm]

Griglia ventilatore

Condensatore

Regolatore

Optyma

TM

Plus

OP-LPHM018

1,3

118U3474

1,8

118U3296

25

118U3477

365

118U3480

H1

118U3483

118U3492

118U3465

OP-LPHM026

3,4

118U3475

3,5

118U3297

68

118U3823 *)

450

118U3481

H2

118U3484

118U3493

118U3465

OP-LPHM048

3,4

118U3475

3,5

118U3297

68

118U3823 *)

450

118U3481

H2

118U3484

118U3493

118U3465

OP-LPHM074

3,4

118U3475

3,5

118U3297

68

118U3823 *)

450

118U3481

H2

118U3484

118U3493

118U3465

OP-LPHM068

3,4

118U3475

3,5

118U3297

68

118U3823 *)

450

118U3481

H2

118U3484

118U3493

118U3465

OP-LPHM096

6,2

118U3476

5

included

130

Full fan assembly **) 118U3829 (500 mm)

H3

118U3485

118U3494

118U3465

OP-LPHM136

6,2

118U3476

5

included

130

Full fan assembly **) 118U3829 (500 mm)

H3

118U3485

118U3494

118U3465

OP-LPHM215

10

118U3716

5

included

130

Full fan assembly **) 118U3829 (500 mm)

H3

118U3485

118U3717

118U3465

OP-LPHM271

10

118U3716

5

included

130

Full fan assembly **) 118U3829 (500 mm)

H3

118U3485

118U3717

118U3465

*) Il motore del ventilatore deve essere sostituito con la versione precedente 118U3478 (75 W) nelle unità con numero di serie fino a xxxxxxCG5212 prodotte prima di dicembre 2012.

**) Per i modelli H3 e H4 prodotti prima della 26a settimana 2014, le parti del ventilatore sono le seguenti:

Condensatore ventilatore - 118U3298 (6 μF)

Motore ventilatore - 118U3479 (130 W)

Pala ventilatore - 118U3833 (f24 in)

Optyma

TM

Plus New Generation - LBP

Parti di ricambio

Descrizione

unità

Resistenza

del carter

[W]

Codice

Sensore

temperatura

(aspirazione e

ambiente)

Codice

Sensore

temperatura

mandata

Codice

Trasmettitore

pressione

mandata

Codice

Trasmettitore

pressione

aspirazazione

Codice

OP-LPHM018

Belt 50

120Z0057

AKS11

084N0003

AKS21A

084N2007

AKS 32R

0 – 32 bar

118U3722

AKS 32R

-1 – 12 bar

118U3721

OP-LPHM026

OP-LPHM048

PTC 35

120Z0459

OP-LPHM074

OP-LPHM068

OP-LPHM096

OP-LPHM136

OP-LPHM215

Belt 70

120Z5040

OP-LPHM271

Adap - Kool®

Modello

Descrizione

Codice

EKA164B

Display esterno e impostazione

084B8575

Equipagg. EKA

Cavo di 6 m per display EKA

084B7299

Equipagg. KA

Kit di montaggio per display EKA

084B8584

EKA178B

Modulo di comunicazione MODBUS

084B8571

EKA175

Modulo comunicazioni LON-Bus

084B8579

EKA183A

Chiave di programmazione

084B8582
