Sistema OLIflex S.P. inox nero

pellet



OLIflex S.P. inox nero pellet, in acciaio inox AISI 316,

è realizzato per essere collegato a stufe a pellet.



La finitura esterna si adatta elegantemente agli ambienti,

la verniciatura è realizzata con resina epossidica

termoindurente resistente a temperature fino a 250°C.

Raccomandiamo di non installare il prodotto su

generatori la cui temperatura d’uscita dei fumi superi

quella precedentemente dichiarata.



Il sistema OLIflex S.P. inox nero pellet si può installare

con qualsiasi tipo di combustibile sia in pressione

che in depressione purché la temperatura non superi

i 250°C. Nella norma UNI 10683 che contempla anche

la combustione del pellet, per motivi strettamente

commerciali, non si è voluto introdurre l’obbligo del

test dell’incendio delle fuliggini (G) come avviene in altri

Stati europei. Per questo motivo, in caso di incendio

(frequente su stufe a legna/pellet) è necessario smontare

tutta la canna fumaria e sostituire tutte le guarnizioni che

permettono la tenuta in pressione positiva rimontando

il tutto sostituendo eventuali elementi danneggiati

(operazione molto complicata in quanto la rimozione

delle guarnizioni bruciate è pressoché impossibile).

Grazie al nostro sistema brevettato, nell’eventualità di

incendio delle fuliggini, non è necessario sostituire le

guarnizioni in quanto non presenti; il sistema meccanico

di giunzione permette, oltre la tenuta in pressione,

la dilatazione di tutta la canna fumaria in funzione

della temperatura e il conseguente ritiro durante il

raffreddamento.



Le norme UNI ed EN sulle canne fumarie non permettono

l’installazione dei sistemi a singola parete all’esterno

degli edifici ma li limitano all’interno di centrali termiche

o in ambienti chiusi.



Tutti i sistemi fumari appartengono alla categoria dei

prodotti da costruzione e devono essere marcati CE

secondo CPR 305/2011.



I sistemi a singola parete in acciaio inox sono marcati

CE secondo la norma UNI EN 1856/2. Anche i condotti

di collegamento ed i canali da fumo devono essere

marcati CE.



I camini/canne fumarie/condotti, per essere marcati

CE, devono essere sottoposti a delle prove molto

gravose come quella di: corrosione dell’acciaio,

(V1 - V2 - V3) della pressione, (N1 - P1 - H1) prove termiche

per la determinazione della temperatura d’esercizio,

(T200 - T600) dell’incendio della fuliggine, (G - O) della

distanza da materiale combustibile (xxx) fornita, dal

produttore, per i sistemi a doppia parete. Le altre prove

da effettuare sono le seguenti: prove ad umido, (W)

ed all’acqua piovana, prove meccaniche di trazione e

compressione ed al vento.

OLIflex S.P. inox nero pellet

system



OLIflex S.P. inox nero pellet, stainless steel AISI 316, is

designed to be installed with pellets stoves.



The external finish is elegant and fits with many places,

the coating is made with thermosetting epoxy resin

resistant to temperatures up to 250°C. We recommend

not to install the product on generators where the flue

can exceed the previously declared temperature.



OLIflex S.P. inox nero pellet single-wall system

can be installed with any type of fuel, under both

positive and negative pressure provided the

temperature doesn’t exceed the 250°C. In the UNI

10683 standard, which regulates also the pellet

combustion, for strictly commercial reasons, it

was decided not to introduce mandatory testing

of fire soot (G) as in other European countries.

For this reason, in case of fire (frequent for wood

stoves/pellet) it is necessary to disassemble the entire

flue system and replace all gaskets that allow the seal in

positive pressure by reassembling the whole, replacing

any damaged element (it is a very complicated operation

because the removal of the seals burned is almost

impossible). Thanks to our patented system, in the event

of soot burning, it is not necessary to replace the seals

because they are not present; the mechanical junction

system allows, in addition to the sealing pressure, the

thermal expansion of the entire chimney as a function

of temperature and the consequent shrinkage during

cooling.



The UNI and EN standards on chimneys do not allow

the installation of single-wall systems outside the

building but only inside central heating systems and in

closed areas.



All flue systems belong to the Construction Products

category and must display the CE mark in compliance

with CPR 305/2011.



The single-wall systems in stainless steel are CE

marked in compliance with the European Standard

UNI EN 1856/2 whereas the double-wall chimney

systems with insulation are CE marked in compliance

with UNI EN 1856/1. The connection pipes and flue

pipes must also be CE marked.



To be CE marked the chimneys/flue pipes/conduit

pipes must undergo some very rigorous tests, such

as: corrosion resistance, (V1 - V2 - V3) pressure,

(N1 - P1 - H1) heat tests to determine the maximum

working temperature, (T200 - T600) soot fire resistance,

(G - O) and minimum distance to combustible material

(xxx), which is indicated by the producer for double-

wall systems. The other tests to be carried out are the

following: condensation resistance (W) and resistance

to rainwater, mechanical tensile and compression tests

and wind tests.
