BOSSINI

BRACCI E SOFFIONI – SHOWER HEADS AND ARMS

Dream Multifunction

RGB Led Lights Cromotherapy

Soffioni Dream/2-3-4 funzioni con luci LED RGB, trasformatore a

basso voltaggio, tastiera di controllo per cromoterapia e flessibile di

alimentazione acqua per installazione a controsoffitto

Dream/2-3-4 function shower heads with RGB LED lights, low

voltage transformer, control keyboard for cromotherapy and

flexible hose for water connection for false ceiling installation

Kopfbrausen Dream/2-3-4 Funktionen mit RGB LED Lichten,

Niederspannungstrafo, Steuertastenfeld für Cromotherapie und

Versorgungsschlauch für Montage an der Zwischendecke

Plafonds de douche Dream/2-3-4 jets avec lumières LED

RGB, transformateur à bas voltage, clavier de contrôle pour

cromothérapie et flexible pour l’alimentation d’eau. Installation à

faux plafond

Rociadores Dream/2-3-4 chronos con luces LED RGB,

transformador de seguridad, teclar de control para cromoterapia y

tubo flexible de alimentación de agua para instalación falso techo

Душевые лейки Dream/2-3-4 функциями, светодиодами LED RGB,

трансформатором низкого напряжения, блоком управления для

Cromoterapia и гибкой подводкой для подключения к водоснабжению.

Установка в подвесной потолок

Materials

Shower head: Stainless steel AISI 304

Nozzles: Silicone

Gaskets: EPDM

Fittings: Brass

Conformity

UNI EN 1112

Hydraulic features

Minimum flow-rate for optimal performace: 16L/min

Min pressure: 1 bar

Max pressure: 5 bar

Electric features

Electric connection: 220-230V ~ 50-60 Hz - max 20w

class of protection II

Dream Lights: 04 low voltage LEDs

Safety Transformer: 230V~ / 7V= 50-60 Hz to be

installed outside the safety area (in compliance with

standard DIN VDE 0100, part 107 – according to

prescription CEI 64/8)

Product Weight With water

Max 11,2 Kg

Size

External: 570 x 470 mm

Cromotherapy control keyboard:

LED lights lighting and colour adjustment

through the waterproof control keyboard

Nebulizzato

Kneipp

Mist spray

Quick drainage

Water-releasing device for DREAM showerheads

All Bossini Dream ceiling-mounted showerheads have a

built-in air suction duct in the water distribution chamber.

This device, patented by Bossini, allows you to immediately

discharge the residual water from the distribution

chamber when you close the mixer, thereby minimizing

water stagnation inside the showerhead. It also enables

the mixing of air and water to give you a bracing water jet.

40

Pioggia

Wide rain spray

Cascata

Cascade spray

Cascata pettine

Rain waterfall spray
