Versione con interasse 50 mm

520

Dettaglio connessioni

70 - 80

E.SIGN

CONTROL

Codice

H [mm]

3540806100210

1220

Il codice riportato in tabella si riferisce al colore BIANCO R01.

Peso a vuoto Superficie

Contenuto

Potenza termica

d'acqua

Watt

Altezza

Larghezza

L [mm]

Interasse

I [mm]

400

Esponente n

Δt = 30°C

520

[Kg]

[m

2

]

[lt]

Δt = 50°C

16,2

0,9

1,3

508

272

1,2225

353

70 - 80

Il codice è comprensivo di VALVOLA, DETENTORE e di TESTA TERMOSTATICA conforme alla norma UNI-EN215:2007 e al D.M. 19/02/2007.

E.SIGN

CONTROL - INTERASSE 50 MM

Larghezza

L [mm]

3540806100220

1220

Il codice riportato in tabella si riferisce al colore BIANCO R01.

Interasse

I [mm]

50

Peso a vuoto Superficie

Contenuto

Potenza termica

d'acqua

Watt

Codice

H [mm]

[Kg]

[m

2

]

[lt]

Δt = 50°C

16,2

0,9

1,3

508

Esponente n

Δt = 30°C

Altezza

520

272

1,2225

Il codice è comprensivo di VALVOLA, DETENTORE e di TESTA TERMOSTATICA conforme alla norma UNI-EN215:2007 e al D.M. 19/02/2007.

Per Δt diversi da 50 utilizzare la seguente formula: resa ricercata = resa termica a Δt 50 x (Δt desiderato/50)^n
