160

Connessioni

radiatore

88

Connessioni

idrauliche

Versione orizzontale

BLOW

®

INOX LUCIDO

Versione verticale

Larghezza

L [mm]

500

1700

Codice

3540640130001

3540640130001

Altezza

H [mm]

1700

500

Interasse

I [mm]

50

50

Peso a vuoto

Superficie

Contenuto

d'acqua

[Kg]

[m

2

]

[lt]

18,7

1,7

1,3

Potenza termica

Watt

Esponente n

1,2247

102

1700

1640

Versione con interasse 50 mm

500

I codici sono comprensivi di valvola, detentore e di testa termostatica conforme alla norma UNI-EN215:2007 e al D.M. 19/02/2007

Per Δt diversi da 50 utilizzare la seguente formula: resa ricercata = resa termica a Δt 50 x (Δt desiderato/50)^n

Δt = 50°C

700

Δt = 30°C

374

102

233

440

12.5

1

6

0
